Hamer Brand Model 1200 BH Open Mouth Bagging Machine


The Hamer Model 1200 BH Bag Hanger provides consistent and reliable bag hanging for a wide variety of pre-made open-mouth paper, woven polypropylene  and polyethylene bags. The Model 1200 BH, when integrated with a bagging scale – automatically picks an empty bag from the stack, individually indexes each bag and then positions the bag on the filler spout. With a focus on electric servo and VFD actuation, the 1200 BH single bag indexing is a significant improvement over traditional bag hangers that pick a bag off a stack of bags.

Are you interested in this product?
We are here to help.

Contact Us

Featured Video

Features

Standard

  • Processes a variety of flat or gusseted bags, including multi-wall paper, laminated woven polypropylene and pinch bags
  • Heavy-duty industrial construction, powder-coated frame for long life in demanding environments
  • Modular design to fit any plant – right hand/left hand configuration
  • Wire mesh interlocked safety doors
  • Single bag indexing for reliable bag placing
  • Servo controlled bag hang arms
  • Heavy-duty clamshell bag clamp
  • Mechanical adjustments for fast bag size change
  • Allen Bradley PLC and Drives with easy to use, color touch screen operator interface
  • Up to 20 bag per minute speed (product/bag dependent).
  • Large 250 bag magazine (bag dependent)
  • NEMA 12, UL Listed control panel

Options

  • In-feed bag stack magazines
  • Upright filled bag conveyors
  • Bag clamp sizes
  • Spouts and chutes to match application
  • FastChange™ Dual Spout sliding interface that allows for quick spout change-over
  • Foot Switch for manual operation
  • Stainless contact points for corrosive environments
  • NEMA 4X stainless steel control enclosures
  • Power configurations
  • Net weight or gross weigh scale
  • Heat sealers or sew sealers
  • Robotic bag palletizer
  • Complete system design

Bag Types

  • Pillow
  • Gusseted
  • Satchel (Grocery) bottom bags
  • Pinch Bottom Open Mouth (PBOM) bags (with optional Handling System)
  • Paper multiwall/Kraft bags
  • Paper multiwall with poly/foil/poly woven liner bags
  • Laminated poly woven bags
  • Polyethylene – PE (4 mil minimum) bags
  • Polypropylene bags
  • Poly Woven Laminate bags
  • BoPP/BOM bags

Bag Sizes

  • Bag Width – 13” to 24”
  • Inner Bag Width – 11.5″ to 24″
  • Bag Length – 17” to 40”
  • PBOM Bag Length – 20″ to 40″
  • Maximum gusset size – 6”

Standard Specs

Electric

230 VAC, 3 PH, 60 HZ

Air

10 CFM @ 80 PSI
