Arpac Brand 708HBD Model


Ultra-compact in design and economical in price, the 708HBD is capable of shrink wrapping up to 40 bundles per minute in a dual lane configuration. This machine offers the flexibility of running in a dual lane mode for higher output, or in a single lane mode to accommodate wider bundles. This model uses motorized pulleys rather than separate drives and chains. This allows for clean, safe operation and a slim machine frame.

Are you interested in this product?
We are here to help.

Contact Us

Featured Video

Features

Standard

  • Compact single-frame stainless steel construction
  • Heavy-duty system for 24/7 operation
  • Right or left-hand mounted infeed and controls
  • Allen-Bradley® programmable logic controller
  • Simple setup and tool-less changeovers for ease of use and minimal downtime
  • Low maintenance conveyor belts do not require tracking adjustments
  • Motorized pulleys eliminate chain drives and operate more cleanly, with reduced maintenance cost and less noise
  • Single stage right-angle infeed conveyor with Intralox belt
  • Tight product transfers allow for small diameter product configurations
  • Powered film unwind for consistent film delivery
  • Low film alert warns that a film changeover will soon be necessary
  • Product hold-down for light products
  • Top and bottom film racks accommodate four 14″ diameter rolls of film
  • No lubrication required for clean and easy maintenance

Options

  • Turbo cooling for quick product handling after shrink tunnel
  • Servo driven main ram
  • Standard or custom infeeds

Film

  • 1.25-2 mil low density polyethylene
  • Clear or randomly printed
  • 15” maximum width
  • 14″ maximum film roll diameter with 3″ core

Product Range

  • Minimum product size: 3/4W x 3/4L x 1/2H  inches
  • Maximum product size: 6W x 11L x 8H  inches
  • Up to 40 packages per minute

Standard Specs

Speed

Up to 40 packages per minute

Electrical Power Requirements

240V or 480V, 3Ph, 60Hz

Compressed Air Requirements

8 SCFM @ 80 psi

Width (across machine)

3/4″ – 6″

Length (flow direction)

3/4″ – 11″

Height Range

1/2″ – 8″

Film Roll Diameter

14”

Film Gauge

1.25-2 mil

Film Type

Low density polyethylene
